Lion Head Titan Slim Bluetooth Keypad

Lion Head Titan Slim Bluetooth Keypad

2 Year Warranty

The TITAN is  a robust Bluetooth keypad from Lion Head Locks!  Engineered for maximum security and convenience, The TITAN offers versatile access options with support for PIN codes, BLE, and Mifare cards, making it ideal for residential, office, and commercial settings.

Crafted from durable zinc alloy with an IP66 rating, The TITAN is designed to withstand challenging weather conditions, from -20°C to 60°C, making it perfect for both indoor and outdoor installations. It can store up to 1,000 Mifare cards, 150 custom PINs, and 150 dynamic PINs, ensuring flexible access control for multiple users.

Equipped with Bluetooth and the option for Wi-Fi connectivity via a gateway, The TITAN allows seamless access management through the mobile app, giving users complete control at their fingertips. Powered by 12V, this keypad is built for reliable performance, ease of installation, and long-lasting durability.

If you’re looking for a powerful, weather-resistant, and user-friendly access solution, The TITAN is the perfect choice.

Features

• Working Temperature: -20C – +60C
• Working Humidity: 0% – 85%
• Pin Capacity: 150 Custom, 150 Dynamic
• Card Types: 13.56MHz Mifare Card, M1 Card
• Card Capacity: 1000
• Unlocking Methods: BLE, WiFi (via Gateway sold seperately), Mifare Card
• IP Rating: IP66
• Material: Zinc Alloy
• Dimensions: 148mm X 43.5mm X 22mm
• Projection: 22MM
• Field Changeable: N/A
• Power: 12V
• Working Current: <80mA
• Lock Output Load: <2A

Download

Datasheet of LHL-KP4-TITAN
