TP-Link InSight S385 Ten-Camera 8MP Full-Colour Bullet Kit with Listed 16-Channel Recorder
Kit at a glance
TP-Link VIGI Kit, 10 x 8MP Full-Color Bullet Network Camera, 16CH NVR.
Included components
- 10 × S385 8MP full-colour bullet cameras with 2.8mm lenses.
- 1 × NVR2016H-16P, listed as a 16-channel PoE+ NVR; exact hardware specifications require confirmation.
- HDD option available
Before you order: Check the included storage and any available upgrade selections for your chosen configuration before ordering. Confirm the camera quantity, recorder configuration and any cabling or monitor requirements in the details below.
Monitor your home or business with ten S385 2.8mm 8MP full-colour bullet cameras and the listed NVR2016H-16P recorder. Capture detailed 4K footage across wide viewing angles, identify human and vehicle events, and communicate through two-way audio. See the recorder confirmation note below before planning power, storage or simultaneous playback.
Important: No hard drive (HDD) is included. Install suitable storage for recorder recording. Camera microSD cards are also not included.
Key features
- Detailed 4K footage: Each S385 captures up to 3840 × 2160 (8MP) at up to 25 fps at 50Hz or 60Hz. Enabling 120dB WDR, People & Vehicle Analytics or 90°/270° image rotation limits frame rate to 20 fps. Recorder decoding and playback capacity are separate.
- Full-colour night monitoring: F1.6 lenses and supplemental white light support colour imaging in darkness. IR and white-light illumination each reach up to 30m.
- Wide-angle coverage: Each 2.8mm lens provides a 111.4° horizontal, 58.8° vertical and 134° diagonal field of view.
- Human and vehicle classification: Distinguish people and vehicles from other objects for more relevant event notifications.
- People & Vehicle Analytics: Attribute-based searching and filtering requires specified VIGI software. Only digital WDR is supported while analytics is enabled.
- Smart detection: Camera events include intrusion, line crossing, region entry/exit, abandoned or removed objects, loitering, people, vehicles, abnormal sound and scene changes, plus motion, tampering and illegal login detection.
- Active deterrence and two-way audio: Built-in microphones and speakers support listening and talking, with audible warnings and flashing white lights.
- Image enhancement: 120dB WDR, BLC, 3D DNR, HLC and SmartIR help manage challenging lighting, subject to the frame-rate and analytics limits above.
- Efficient compression: H.265+/H.265/H.264+/H.264 main-stream options help manage bandwidth and recording storage.
- Camera storage: Each camera supports microSD up to 512GB, not included. Recorder storage specifications require confirmation.
- Flexible camera power: Each S385 supports 12V DC or IEEE 802.3af/at PoE. Confirm the supplied recorder's PoE ports and shared power budget before installation.
- Outdoor-ready bullet cameras: IP67-rated metal housings operate from -30°C to 60°C. This rating does not apply to the recorder.
Camera technical specifications
| Included cameras | 10 × InSight S385 (2.8mm), bullet design |
|---|---|
| Sensor and resolution | 1/2.7-inch progressive scan CMOS; 3840 × 2160 (8MP) |
| Lens | Fixed 2.8mm, F1.6; M12 × P0.5 mount |
| Field of view | 111.4° horizontal; 58.8° vertical; 134° diagonal |
| Minimum illumination | 0.005 lux; 0 lux with IR or white light |
| Illumination | Two 850nm IR LEDs and two white LEDs; each type up to 30m; automatic, scheduled, always-on or off control |
| Shutter and day/night | 1/3–1/10000 second; slow shutter; IR cut filter |
| Manual adjustment | Pan 0–360°; tilt 0–90°; rotation 0–360° |
| DORI distances, 2.8mm | Detect 85m; observe 35m; recognise 17m; identify 8m |
| Frame rate | Up to 25 fps at 50Hz or 60Hz; up to 20 fps with 120dB WDR, People & Vehicle Analytics or 90°/270° rotation enabled |
| Main-stream resolutions | 3840 × 2160; 2560 × 1440; 2304 × 1296; 2048 × 1280; 1920 × 1080; 1280 × 720 |
| Sub-stream resolutions | 848 × 480; 704 × 576; 640 × 480; 640 × 360; 352 × 288; 320 × 240 |
| Compression and bitrate | Main: H.265/H.265+/H.264/H.264+, 256Kbps–8Mbps; sub: H.265/H.264, 64Kbps–1Mbps; CBR/VBR |
| Image enhancement | 120dB WDR; digital WDR only with analytics; BLC, 3D DNR, HLC and SmartIR; signal-to-noise ratio ≥52dB |
| Privacy and ROI | Four privacy masks; one region of interest |
| Audio | Built-in microphone and speaker; two-way audio; noise filtering; 8kHz sampling; 64Kbps G.711 A-law |
| Network | One 10/100Mbps PoE Ethernet port; ONVIF Profiles S/T/G |
| Local storage | MicroSD up to 512GB, not included |
| Management | VIGI App, Security Manager, NVR, web, VMS Local and Cloud VMS |
| Power | 12V DC ±5%, maximum 10.5W; or 802.3af/at PoE class 0, maximum 11.5W |
| Housing and environment | Metal; IP67; -30°C to 60°C; humidity ≤95%, non-condensing |
| Dimensions and weight | 74 × 184 × 74mm; 0.525kg per camera |
| Camera package accessories | Quick start guide, waterproof cable attachments and mounting accessories |
Recorder details and confirmation required
| Listed model | NVR2016H-16P |
|---|---|
| Listed description | 16-channel PoE+ NVR; verify against supplied hardware |
| Channel allocation | Ten cameras on the listed 16-channel recorder would leave six channels, subject to confirmed compatibility, bandwidth and power capacity |
| Storage | HDD not included; confirm number of SATA bays and supported HDD capacity. The existing kit listing specifies one bay. |
| Power and performance | Confirm PoE port count, total PoE budget, incoming/outgoing bandwidth, display outputs and simultaneous decoding/playback limits from the exact model's datasheet |
Recorder datasheet mismatch: The included recorder is listed as NVR2016H-16P, but the linked recorder document is for NVR2016H (UN) V2. These model names differ, so the linked document does not establish the supplied recorder's PoE, storage or playback specifications. Confirm the supplied model and hardware version before installation. Camera recording resolution, display output resolution and simultaneous decoding capacity are separate specifications; do not assume all ten cameras can be displayed or played back together at full 8MP resolution and maximum frame rate.
